WeAct BlackPill STM32F411CEU6 STM32F4 STM32 Core Board Learning Board Development Micropython

WeAct Studio Offical Store A studio dedicated to designing unique electronic modules. Technical support, quality assurance WeAct Studio STM32F411CEU6 BlackPill The version is V3.1.Board with our LOGO and version number is our board, ST new original chip, quality assurance. WeAct Studio STM32F411CEU6 BlackPill The version is V3.1.Board with our LOGO and version number is our board, ST new original chip, quality assurance. WeAct Studio BlackPill Download Link BlackPill Product Details 1. STM32F411CEU6 100Mhz, 128Kb RAM, 512Kb ROM 2. 25Mhz high speed crystal oscillator & 32.768Khz 6PF low speed crystal oscillator 3. Gold sinking process is adopted, lead-free process is used, and the needle arrangement is gold-plated, which is more environmentally friendly 4. Support C language programming development 5. There are 3 buttons, reset key, BOOT0 key, user key 6. The use of the latest original chip, high quality crystal vibration Memory 512Kbytes of Flash memory 128 Kbytes of SRAM SPI Flash(Optional) Clock and Power Supply • 3.3V-5V power input, 3.3V LDO maximum output current 100mA • USB C interface is used, and a diode is serial to prevent power backflow • 25Mhz high speed crystal oscillator • 32.768K 6PF low speed crystal oscillator Interface and Key • USART x 3, I2C x 3, SPI x 5,USBFS x 1 • ADC x 1(10),I2S x 5,CRC x 1,TIM x 8 • 20 Pin 2.54mm pitch I/O interface x 2 • 4 Pin 2.54mm pitch SW debug interface x 1 • USB C (Type C) interface x 1 • User keys Key (PA0) x 1 • Reset key NRST x 1 • Boot0 key x 1 Design and Quality • Adopt lead-free welding process, sink gold PCB • Boot is set by pressing a key • Using high quality crystal oscillator, metal shell, can be good vibration • Always use the original chip • GitHub regularly updates the chipmark used to make sure that you are buying new chips Use Items / Download Hex How to enter ISP (serial port /USB download) • Method 1: Press Boot0 and NRST at the same time and release NRST. After 0.5s, release Boot0 and enter ISP mode • Method 2: In the power off state, press Boot0, power on, wait for 0.5s, release to enter ISP mode • Serial port download: use USB to serial port to connect the core board PA9,PA10 can be, do not use USB port power supply • USB download: use the data cable to connect to the computer • Weact Studio Download Tool Dimensions and Accessories Dimensions: 52.38mm x 20.78mm Accessories: • STM32F411CEU6 Core Board x 1 • 20 Pin 2.54mm pitch row Pin x 2 • 4Pin 2.54mm pitch back bend row needle x 1 Provide Altium Designer Core Board Packaging, see DATA
