IMX219-83 Dual 8MP Stereo Camera with IMU, for Jetson Nano, Orin Nano, Raspberry Pi 5 and CM4

Binocular Camera Module, Dual IMX219, 8 Megapixels, Stereo Vision, Depth Vision Binocular Stereo Vision Camera Module IMX219 | 8 Megapixels Features At A Glance Adopts IMX219 chip, onboard dual 8Megapixels cameras Suitable for AI vision applications like depth vision and stereo vision Supports Jetson Nano Developer Kit (B01) and JETSON-NANO-DEV-KIT Development Kit,also for Jetson Orin Nano Supports Raspberry Pi CM3/CM3+/CM4 base boards like Compute Module IO Board Plus, Compute Module POE Board, etc Specifications PIXELS 8 Megapixels SENSOR IMX219 CAMERAS CMOS size 1/4inch APERTURE (F) 2.4 Resolution 3280 × 2464 (per camera) Focal Length 2.6mm FIELD OF VIEW 83°(D) 73°(H) 50°(V) DISTORTION Baseline Length 60mm ICM20948 Accelerometer Resolution: 16-bit Measuring Range (configurable): ±2, ±4, ±8, ±16g Operating Current: 68.9uA Gyroscope Resolution: 16-bit Measuring Range (configurable): ±250, ±500, ±1000, ±2000°/sec Operating Current: 1.23mA Magnetometer Resolution: 16-bit Measuring Range: ±4900μT Operating Current: 90uA DIMENSIONS 24 × 85mm APPLICATIONS AI vision applications like depth vision and stereo vision. Support Jetson Nano for reference only, Jetson Nano Developer Kit (B01) is NOT included. Product Show Outline Dimensions Resources WIKI: www.waveshare.com/wiki/IMX219-83_Stereo_Camera • Resources for different product may vary, please check the wiki page to confirm the actually provided resources. Packing List 1 x IMX219-83 Stereo Camera 2 x FFC 15Pin Cable 2 x FFC 15Pin to 22Pin Cable 1 x PH2.0 4Pin Cable
